Candlestick chart

[Oleg_Troyansky]

Hi folks!

Does anyone have an example of a nice looking Candlestick chart? I made one, using a Combo chart and a combination of bars and symbols, but it only looks decent when many bars are available. As soon as the user selects a single item, the bar automatically becomes too wide, and the whole picture gets really ugly...

Any good ideas are appreciated.

If anyone knows of a good extension that can be used for a Candlstick, please let me know.

Appreciate your feedback,

Oleg Troyansky

[Gysbert_Wassenaar]

Can't you abuse the boxplot wizard to that purpose?

[Oleg_Troyansky]

I tried the Box plot... Doesn't look too nice either. The blocks also become too wide with just a few available values.

Thanks fo the suggestion though!

[Anonymous]

Oleg,

Before the boxplot was avaialble (or it was and I didn't know yet), I used line chart with the conditional line style.  The attribute expression defined the thikness of the line between two variables:

if(SAT>=vLowIncomeL AND SAT<vLowIncomeH, '<W10>')

Had to use quite a number of variables, but it works.  And had colors, unlike the "native" QV boxplot.

Hope it helps.

Regards,

Michael

[Oleg_Troyansky]

Thanks Michael!

This is an interesting idea... worth exploring...

[whiteline]

Hi.

I've also used something like this to display ranges, max/min and distribution approximation.

The line style is also useful '<W1><S2>'

The only lack of fractional line width and aliasing makes sad...
