Set Analysis with subfield and getfieldselections

Scenario: I would like to use a "Combo Chart" to show 'one selected FinYear' compared with 'another selected FinYear'. I would like the user to be able to choose which Financial Years to compare, therefore this will not always be a comparison of the previous year.

I have a listbox of the FinYear field which contains values such as '2012-13', '2013-14' and '2014-15'

My first expression (that doesn't work) is

=sum({<FinYear={"$(=subfield(GetFieldSelections(FinYear),',',2))"}>}Flag)   Display Options= Bar

and my second expression (also doesn't work) is

=sum({<FinYear={"$(=subfield(GetFieldSelections(FinYear),',',1))"}>}Flag)   Display Options= Line

The user would then select two FinYears (for example '2012-13' and '2014-15') and the chart should show a bar for 2014-15 and a line for 2012-13. Instead the chart says "No data to display".

I have a text box with the following expression to test the values...

=GetFieldSelections(FinYear) & chr(10) &
SubField(GetFieldSelections(FinYear),',',2)& chr(10) &
SubField(GetFieldSelections(FinYear),',',1)

And this shows:

2012-13, 2014-15

2014-15

2012-13

Why do my chart expressions not work?

1 Solution

Accepted Solutions
maxgro
MVP
MVP

I also think you can use max and min of FinYear instead of subfield......

something as

sum({<FinYear={'$(=minstring(FinYear))'}>} Flag)

View solution in original post

7 Replies
Anonymous
Not applicable

Try this

=sum({<FinYear={"$(=subfield(concat(GetFieldSelections(FinYear),','),',',2))"}>}Flag)

=sum({<FinYear={"$(=subfield(concat(GetFieldSelections(FinYear),','),',',1))"}>}Flag)

Not applicable

Hi,

Try like this may be it will work

your first expression

=sum({<FinYear={"$(=subfield(GetFieldSelections(max(FinYear)),',',2))"}>}Flag)
Display Options for Bar

and your second expression is

=sum({<FinYear={"$(=subfield(GetFieldSelections(max(FinYear)),',',1))"}>}Flag)
Display Options for Line

lawrenceiow
Creator II
Creator II
Author

Thank you for your reply Karthigayan C but this did not work.

I took your expression out of the dollar expansion bit and put it into a textbox =subfield(concat(GetFieldSelections(FinYear),','),',',2) and this correctly showed 2014-15 so I don't know why your expression did not work. The only thing that I can think of is, on one occasion when I was trying out various options the text box showed 1999 - ie it had evaluated the 2014-15 as an expression - 2014 minus 15.  If that is what's going on in the chart how do I stop it from evaluating the expression?

lawrenceiow
Creator II
Creator II
Author


Thank you for your reply rakesh goud but it did not work. I tried your expression in a text box (ie the dollar expansion bit) and the text box showed "Error: Error in expression: Nested aggregation not allowed"

maxgro
MVP
MVP

some little changes

sum({<FinYear={'$(=trim(subfield(GetFieldSelections(FinYear),',',2)))'}>} Flag)


maxgro
MVP
MVP

I also think you can use max and min of FinYear instead of subfield......

something as

sum({<FinYear={'$(=minstring(FinYear))'}>} Flag)

lawrenceiow
Creator II
Creator II
Author

Brilliant! Thanks Massimo Grossi, it worked

Of course! There's a space in the GetFieldSelections results, I'm thinking it's "2014-15" when

actually it's " 2014-15". Pretty obvious when I look at it now.

Whilst using the TRIM function definitely works I think I prefer your suggestion of MinString and

MaxString as these are shorter to use than the trim, subfield, getfieldselections combination.

Thanks again for your help.
