Text Colour and Background colour in a Pivot Chart

[Anonymous]

Hi all,

sounds like stupid question but i just can't get the text colour or background colour to work in this instance...

I have been able to in other instances but here it's not working for me...

I have qlikview pivot chart, in which I have a dimension (ISHCQTYAvailable) which has been pre-calculated in the load script, this gives the quantity available for a particular product.

I want the text to be red if it's in the negative, and green if it's in the positive and black, if it's just 0.

So in "Text Colour" under that dimension I have the following:

=IF(ISHCQTYAvailable > 0, Green(),

     IF(ISHCQTYAvailable < 0, Red(), Black()))

why isn't this working for me - any ideas?

Thanks in advance everybody!!

Fab

[Anil_Babu_Samineni]

Can you provide work file to test

[vvira1316]

You are trying to do Dimension background color or the expression background color?

[Anonymous]

I would love to Anil,

But unfortunately this is part of a pretty large qlikview report, which is connected to our in house DB via ODBC...

I was hoping someone would be able to comment on my code...

thanks for your interest though...

Fab

[prma7799]

Try like this or Please share some sample app

Go to expression >>Text Color >>

if( ISHCQTYAvailable >=0    ,Green(),

if( ISHCQTYAvailable < 0  ,red(),

Black() ) )

[Anonymous]

Hi Vijay,

My field is a dimension, not an expression...

It's been pre-calculated in the load script...

Thanks

[prma7799]

Please share some sample app

[Anonymous]

Hi all,

thanks for your input...

I've just converted by pivot table into a straight table and the colours work no problems

Does anyone know how I can make text and background colours work (in dimensions) within a pivot table?

I don't understand why a feature like this would work in a straight chart but not a pivot chart???

[prma7799]

You can use it in dimension

Go to dimension >>Background Color >> ( Put those column no. which you want to apply on that basis)

e.g.

if( Column(2)>=0    ,Green(),

if( Column(2)< 0  ,red(),

Black() ) )
